Specification

• Of Pockets:

• • Main Module: 4+2

  • Expansion Module: 2 pocket/unit ｜ Max 16 + 2 pockets

• Hopper Capacity: 1500

• Stacker Capacity: 500

• Reject Capacity:

  • Reject 1: 100

  • Reject 2: 200

• Normal Count: 1000

• Value Count: 1000

• Fitness: 1000

• S/N Speed: 1000

• Dimension (W/H/D):

  • Main: 731X534X392mm

  • Ext. (2P): 276X348X392mm

• Weight:

  • Main: 55kg

  • Exp: 10kg

• Functions:

  • Multi Curr. Auto 16 / Mix 10 ｜ Batch Card

  • Face & Orientation ｜ S/N (OCR) ｜ Fitness

• S/N Reading: O

• Fitness (F type): O

• Currency: Upto 12

• Sensor:

  • Dual CIS ｜ UV ｜ MG (18ch) ｜ IR ｜ US

• Connectivity/Interface:

  • Serial Port x 4

  • LAN x 2 (Normal & Debug)

  • USB x 1

• OS: Linux

• Screen: 7" Touch Display (800 x 480 Pixels)

• Options & Special Features:

  • Dual Pocket Expansion Structure

  • Interactive Pocket Structure

  • Batch Card support

  • Support External Data Screen

• Certification: CE_EMC ｜ CE_LVD ｜ CB ｜ CQC ｜ FCC ｜ KC

Specification subject to change without notice.
