Aruba JL683A Instant On 1930 JL683A Port Gigabit PoE+ Switch with 4×10Gbps SFP+ Uplinks, 195 W PoE Budget
Estimated delivery within UAE 1-2 working days
Delivery to other countries 3-5 working days
Special Offers
Epson EcoTank L5590 All-in-One Printer A4 Multifunction with ADF, Fax, Wi-Fi, Borderless, Wireless, Low Cost Printing for Home & Office
Canon PIXMA G3470 Wireless 3-in-1 Colour MegaTank Printer – Fast Printing, Huge Savings, Refillable Ink, Black
Epson SureColor SC-T5405 Wireless Printer with Stand – 2400 x 1200 DPI, Ultrachrome XD2 Ink, 4pl Droplet Technology, 800 Nozzles, White
-
24 Gigabit RJ‑45 PoE+ ports plus 4 SFP+ 1/10 Gbps uplinks.
-
195 W PoE budget to power access points, cameras, IP phones.
-
High performance: 128 Gbps switching capacity; forward rate of ~ 95.23 Mpps.
-
Low latency: ~1.3 µs at 10 Gbps, <2.4 µs at gigabit speeds.
-
Efficient internal design with ARM Cortex‑A9 @ 800 MHz, 512 MB RAM, 256 MB flash.
-
Moderate power draw: ~ 234 W maximum; ~ 19.3 W when idle.
-
Rack‑mount 1U form factor; dimensions 44.25 × 26.47 × 4.39 cm; weight ~ 3.5 kg.
-
Managed via Instant On portal / Web / SNMP; supports VLANs, QoS, link aggregation, etc.
Specifications
-
Model: Aruba Instant On 1930 JL683A
-
Ports:
• 24 × RJ‑45 autosensing Gigabit Ethernet ports (10/100/1000 Mbps), PoE+ Class 4 support
• 4 × SFP+ ports (1/10 Gbps uplinks) -
PoE Budget: 195 Watts total (Class 4)
-
Switching Capacity: 128 Gbps
-
Forwarding Rate / Throughput: ~ 95.23 million packets per second (Mpps)
-
Latency:
• < 4.7 µs at 100 Mbps
• < 2.4 µs at 1 Gbps
• ~ 1.3 µs at 10 Gbps -
Processor & Memory: ARM Cortex‑A9 @ 800 MHz; 512 MB SDRAM; 256 MB Flash; packet buffer ~1.5 MB
-
MAC Address Table Size: ~ 16,000 entries
-
Operating Voltage: 100‑127 / 200‑240 VAC, 50/60 Hz
-
Power Consumption: Max ~ 234 W; Idle ~ 19.3 W
-
Physical Dimensions: 44.25 × 26.47 × 4.39 cm; 1U rack height
-
Net Weight: ~ 3.50 kg
-
Environmental: Operating temperature 0 °C to 40 °C; Relative humidity 15%‑95% non‑condensing
-
Management & Features: Smart‑managed via Aruba Instant On Portal, Web GUI, SNMP; rack‑mountable, optionally wall‑ or shelf‑mounted; supports VLANs, link aggregation, QoS, etc.
