Ubiquiti AF-5G30-S45 airFiber X 5 GHz 30 dBi Slant 45 Antenna – High-Performance Point-to-Point Backhaul Solution
Estimated delivery within UAE 1-2 working days
Delivery to other countries 3-5 working days
Special Offers
Epson EcoTank L5590 All-in-One Printer A4 Multifunction with ADF, Fax, Wi-Fi, Borderless, Wireless, Low Cost Printing for Home & Office
Canon PIXMA G3470 Wireless 3-in-1 Colour MegaTank Printer – Fast Printing, Huge Savings, Refillable Ink, Black
Epson SureColor SC-T5405 Wireless Printer with Stand – 2400 x 1200 DPI, Ultrachrome XD2 Ink, 4pl Droplet Technology, 800 Nozzles, White
-
Designed for long-range point-to-point (PtP) wireless links
-
Operates within the 5.1 – 5.9 GHz frequency range
-
Provides a high gain of 30 dBi for enhanced signal strength
-
Features a dual linear polarization for improved signal clarity
-
Built to withstand wind speeds up to 200 km/h (125 mph)
-
Complies with ETSI EN 302 326 DN2 standards
-
Includes universal pole mount and weatherproof RF connectors
-
Compact dimensions of 650 x 650 x 386 mm for versatile installation
Specifications
-
Model: AF-5G30-S45
-
Frequency Range: 5.1 – 5.9 GHz
-
Gain: 30 dBi
-
Beamwidth: +45°: 5.8° (3 dB), -45°: 5.8° (3 dB)
-
Front-to-Back Ratio: 30 dB
-
Maximum VSWR: 1.6:1
-
Wind Survivability: 200 km/h (125 mph)
-
Wind Loading: 790 N @ 200 km/h (178 lbf @ 125 mph)
-
Polarization: Dual Linear
-
Cross-Polar Isolation: 35 dB minimum
-
ETSI Specification: EN 302 326 DN2
-
Mounting: Universal pole mount, airFiber X radio bracket, and weatherproof RF connectors included
