Display

-Screen Size: 2.4-inch
-Resolution: 320 × 240
-Type: LCD-TFT display screen

Audio
-Audio Output: 1 loudspeaker, 1 buzzer

-Network
Wired Network: TCP/IP, 10/100Mbps, self-adaptive
Wi-Fi: Supported

Interfaces
-Network Interface: 1
-RS-485: 1
-Wiegand: 1
-Lock Control: 1
-Exit Button: 1
-Door Contact Input: 1
-Alarm Input: 1
-Alarm Output: 1
-TAMPER: 1
-USB: 1

Capacity
-Card Capacity: 3000
-Fingerprint Capacity: 3000
-Event Capacity: 100,000

Authentication
-Card Type: M1 card
-Card Reading Distance: 0 to 4.5 cm
-Card Reading Duration: ＜ 1 second
-Fingerprint Module: Optical fingerprint module
-Fingerprint Comparing Mode: 1:1 and 1
-Fingerprint Recognition Duration: ＜ 1 second

General
-Indicator: Power/status (red/green)
-Power Supply: 12 VDC/1 A
-Working Temperature: -10°C to +55°C (14°F to +131°F)
-Working Humidity: 10% to 90% (non-condensing)
-Color:
Black (included)
Gold (optional)
Silver (optional)
White (optional)

Dimensions
-Dimensions (W x H x D): 205 mm × 76.5 mm × 37 mm (8.07" × 3.01" × 1.46")

-Installation
Mounting Type: Surface mounting

Language Support
-English, Vietnamese, Brazilian Portuguese, Spanish, French, Italian, Arabic, Thai, Turkish, Indonesian, and Ukrainian
