Technical Specifications

Mechanical

Dimensions Ø48.5 x 159.5 mm (Ø1.9 x 6.28")

Weight 400 g (0.88 lb)

Enclosure material Plastic, aluminum

Mount materials Plastic

Weatherproofing IPX5

Hardware

Networking interface (1) GbE RJ45 port

Management interfaces Ethernet

Bluetooth

Power method PoE

Power supply UniFi PoE switch

48V, 0.32A PoE adapter (included)

Supported voltage range 44—57V DC

Max. power consumption 11.4W

Max. TX power

2.4 GHz

5 GHz

22 dBm

26 dBm

MIMO

2.4 GHz

5 GHz

2 x 2 (UL MU-MIMO)

4 x 4 (DL/UL MU-MIMO)

Throughput rate

2.4 GHz

5 GHz

573.5 Mbps

4.8 Gbps

Antenna gain

2.4 GHz

5 GHz

3 dBi

5 dBi

LEDs White/blue

Button Factory reset

Mounting Wall, desktop, pole mount (Included)

Ceiling mount (Optional)

Operating temperature -30 to 60° C (-22 to 140° F)

Operating humidity 5 to 95% noncondensing

Certifications CE, FCC, IC

Software

WiFi standards 802.11a/b/g

WiFi 4/WiFi 5/WiFi 6

Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)

BSSID 8 per radio

VLAN 802.1Q

Advanced QoS Per-user rate limiting

Guest traffic isolation Supported

Concurrent clients 300+

Zero wait DFS Yes*

*Supported with upcoming firmware versions

Supported Data Rates

802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b 1, 2, 5.5, 11 Mbps

802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (WiFi 4) 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)

802.11ac (WiFi 5) 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)

802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

Application Requirements

UniFi Network Version 6.2.51 and later
