Camera Specifications:

• Image Sensor: 1/1.8" Progressive Scan CMOS
• Max. Resolution: 2688 × 1520
• Minimum Illumination:
  • Color: 0.0005 Lux @ (F1.0, AGC ON)
  • 0 Lux with supplementary light
• Shutter Time: 1/3 s to 1/100,000 s
• Day & Night: IR cut filter for true day/night functionality
• Angle Adjustment:
  • Pan: 0° to 360°
  • Tilt: 0° to 75°
  • Rotate: 0° to 360°

Lens:

• Lens Type: Fixed focal lens (2.8 mm or 4 mm)
• Focal Length & FOV:
  • 2.8 mm: Horizontal FOV: 111.1°, Vertical FOV: 57.6°, Diagonal FOV: 138.5°
  • 4 mm: Horizontal FOV: 95.2°, Vertical FOV: 48.3°, Diagonal FOV: 117.4°
• Lens Mount: M16
• Iris Type: Fixed
• Aperture: F1.0
• Depth of Field:
  • 2.8 mm: 2.5 m to ∞
  • 4 mm: 3.1 m to ∞
• DORI (Detection, Observation, Recognition, Identification):
  • 2.8 mm: D: 61 m, O: 24 m, R: 12 m, I: 6 m
  • 4 mm: D: 75 m, O: 30 m, R: 15 m, I: 7 m

Illuminator:

• Supplement Light Type: IR, White Light
• Supplement Light Range: Up to 30 m
• Smart Supplement Light: Yes
• IR Wavelength: 850 nm

Video:

• Main Stream:
  • 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
  • 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
• Sub-Stream:
  • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
  • 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
• Third Stream (Supported under certain settings):
  • 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
  • 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
• Video Compression:
  • Main Stream: H.265/H.264/H.264+/H.265+
  • Sub-Stream: H.265/H.264/MJPEG
  • Third Stream: H.265/H.264
• Video Bit Rate: 32 Kbps to 8 Mbps
• Bit Rate Control: CBR, VBR
• Scalable Video Coding (SVC): H.264 and H.265 encoding
• Region of Interest (ROI): 1 fixed region for main and sub-stream

Audio:

• Audio Compression: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC
• Audio Bit Rate: 64 Kbps (G.711ulaw/alaw), 16 Kbps (G.722.1, G.726), 16-64 Kbps (AAC-LC), 32-192 Kbps (MP2L2), 8-320 Kbps (MP3)
• Audio Sampling Rate: 8 kHz, 16 kHz, 32 kHz, 44.1 kHz, 48 kHz
• Environmental Noise Filtering: Yes

Network:

• Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, SRTP, SFTP
• Simultaneous Live View: Up to 6 channels
• API: Open Network Video Interface (Profile S, G, T), ISAPI, SDK, ISUP
• User/Host: Up to 32 users with 3 user levels (Administrator, Operator, User)
• Security: Password protection, HTTPS encryption, 802.1X authentication, IP address filter, TLS 1.1/1.2/1.3, MAC address authentication
• Network Storage: NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
• Client: iVMS-4200, Hik-Connect, Hik-Central
• Web Browser Compatibility:
  • Plug-in live view: IE 10, IE 11
  • Plug-in free live view: Chrome 57+, Firefox 52+, Edge 89+

Image Settings:

• Image Enhancement: BLC, HLC, 3D DNR
• Day/Night Switch: Day, Night, Auto, Schedule
• Wide Dynamic Range (WDR): 130 dB
• Privacy Mask: 4 programmable polygon privacy masks
• SNR: ≥ 52 dB
• Image Parameters: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance (adjustable via client software or web browser)

Event & Smart Features:

• Basic Event: Motion detection, video tampering, exception
• Linkage: Upload to FTP/NAS/memory card, trigger recording, capture, email notification
• Smart Event: Scene change detection
• Deep Learning Function: Face Capture
• Perimeter Protection: Line crossing, intrusion, region entrance/exit, target classification (human, vehicle)

General:

• Power: 12 VDC ± 25%, 0.41 A (max. 5 W) or PoE IEEE 802.3af (Class 3, max. 6 W)
• Material: Metal (Cover, Body, Bracket)
• Dimensions: Ø138.3 mm × 115.4 mm (Ø5.4" × 4.5")
• Package Dimensions: 170 mm × 170 mm × 160 mm (6.7" × 6.7" × 6.3")
• Weight: Approx. 770 g (1.7 lb), with package: Approx. 1040 g (2.3 lb)
• Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity ≤ 95% (non-condensing)
• Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity ≤ 95% (non-condensing)
• Protection: IP67 (IEC 60529-2013)
• Approvals: CE, UL, CB, BIS, EMC, RoHS compliant

Languages Supported: 33 languages, including English, Russian, French, Spanish, German, Italian, Arabic, Chinese, and more.
