Hikvision DS-7604NI-Q1/4P 4-ch 1U 4 PoE 4K NVR

General

• Power Supply: 48 VDC, 1.35 A
• Consumption: ≤ 10 W (without HDD, and PoE off)
• Working Temperature: -10 to +55º C (+14 to +131º F)
• Working Humidity: 10% to 90%
• Dimension (W × D × H): 320 × 240 × 48 mm (12.4" × 9.4" × 1.9")
• Weight: ≤ 1 kg (without HDD, 2.2 lb.)
• Certification:
  • FCC: Part 15 Subpart B, ANSI C63.4-2014
  • CE: EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017

Video Input

• IP Video Input: 4-ch
• Video and Audio: 1-ch; 4-ch
• Incoming Bandwidth: 40 Mbps
• Outgoing Bandwidth: 80 Mbps

Video Output

• HDMI Output:
  • 1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz
  • HDMI/VGA simultaneous output
• VGA Output:
  • 1-ch, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
  • HDMI/VGA simultaneous output
• Video Output Mode: HDMI/VGA simultaneous output

Audio

• Audio Output: 1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 k Ω)
• Audio Compression: G.711ulaw/G.711alaw/G.722/G.726

Recording

• Stream Type: Video, Video & Audio
• Decoding:
  • Decoding Format: H.265+, H.265, H.264+, H.264
  • Decoding Capability: 1-ch@8 MP (30 fps)/5-ch@1080p (30 fps)
  • Recording Resolution: 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
  • Synchronous Playback: 4-ch

Network

• Remote Connection: 32
• Network Protocol: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
• Network Interface:
  • 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
  • 4, RJ-45 10/100 Mbps self-adaptive Ethernet interface (PoE Interface)
• PoE: IEEE 802.3 af/at

Storage

• SATA Interface: 1 SATA interface
• Capacity: Up to 8 TB capacity for each disk
• USB Interface: 2 × USB 2.0

Alarm

• Alarm In/Out: N/A (4/1 is optional)
