Brother QL820NWB Professional, Ultra Flexible Label Printer with Multiple Connectivity options | Brother QL820NWB

Specifications

Dimensions

• Carton Dimensions (W" x D" x H"): 7.250 " x 11.750 " x 9.000 "

• Carton Weight (lbs): 5.600

• Unit Dimensions (W" x D" x H"): 5.0" x 9.2" x 5.7"

• Unit Weight (lbs): 2.5

Hardware Features

• Cutter Life: up to 300,000 (die-cut labels) 150,000 (continuous labels)

• Cutter Type: Automatic

• Housing Color: White / Black

• Interface Types: Bluetooth wireless technology (Ver.2.1+EDR SPP, BIP, OPP, HCRP and iAP/MFI supported) interfaces, USB Host, Wireless (b/g/n), Ethernet, Wireless Direct

• LCD Display: Yes

• Maximum Label Length: 3 feet

• Maximum Label Width (in.): 2.4

• Maximum Print Resolution (DPI): 300 x 600

• Maximum Print Speed (labels per min.): 110

• Maximum Print Width (in.): 2.3

• Maximum Print Width (mm): 58

• Memory for Transferred Data (MB): 7

• Network Compatibility: Built-In

• Number of Templates for Transfer Data: 255

• Operation Modes: PC Connected, Stand Alone (ESC/P or P-touch Template)

• Options: Optional Li-ion Battery (PA-BU-001)

• Printer Emulation: Raster

• Printer Memory (MB): 7.8

• Printer Technology: Direct Thermal

• Standard Interfaces: Wireless 802.11 b/g/n, Ethernet, Wi-Fi Direct, Hi-Speed USB 2.0

• Standard Memory (MB): 7

• Tape Sizes: Die-Cut, Continuous

Power

• ENERGY STAR Certified: Yes

• Power Source: 100-240V - 50/60Hz 1.5A

Software Features

• Bar Code Types: PC Connected: CODE39, IMb, CODE128, UCC/EAN128 (GS1-128), ITF (I-2/5), CODABAR (NW-7), UPC-A, UPC-E, EAN13, EAN8, ISBN-2 (EAN13 AddOn2), ISBN-5 (EAN13 AddOn5), Laser Barcode, POSTNET, RSS (RSS14 Standard, RSS14 Truncated, RSS14 Stacked, RSS14 Stacked Omni, RSS Limited, RSS Expanded, RSS Expanded Stacked), PDF417 (Standard, Truncate, Micro), QR code (Model1, Model2, Micro), Data Matrix (ECC Square, ECC Rectangular), MaxiCode (Model2, Model3, Model4, Model5), GS1 Databar Composite, Aztec Barcode

• Bar Code Types: Stand Alone: CODE39, CODE93, UPCEETENTION, CODE128, UCC/EAN128 (GS1-128), ITF (I-2/5), CODABAR (NW-7), UPC-A, UPC-E, EAN13, EAN8, RSS (RSS14 Standard, RSS14 Truncated, RSS14 Stacked, RSS14 Stacked Omni, RSS Limited, RSS Expanded, RSS Expanded Stacked), PDF417 (Standard, Truncate, Micro), Data Matrix (ECC Square, ECC Rectangular), MaxiCode (Model2, Model3, Model4, Model5)

• Database File Compatibility: CSV, TXT, MDB, XLS

• Font Style: True Type

• Labeler Features: Date/Time Stamp, Rotate Printing, Vertical Printing, Mirror Printing

• Maximum Number of Print Copies: 9999

• Microsoft Word/Outlook/Excel Add-ins: Yes

• Mirror Printing: Yes

• Mobile Device Compatibility: AirPrint, Brother iPrint&Label

• Mobile Device Printing App: Yes

• Multi-copy Print: Up to 9999 copies

• Operating System Compatibility: Windows Vista, Windows 7, Windows 8/8.1, Windows 10, Windows Server 2003, Windows Server 2008

• Postage Ready: Yes

• Rotate Printing: Yes

• Symbols for Windows (Clipart in editor): 1,379

• Time/Date Stamp: Standalone

• Vertical Printing: Yes

System Requirements

• SDK Support: Yes

• Security Functions: Enterprise Security (802.1x)

• Security Protocols (Wired): 802.1x (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)

• Security Protocols (Wireless): 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)

• Software Included: P-touch Editor 5.2 for Windows, P-touch Address Book 1.2 for Windows, P-touch Editor 5.1 for Mac, P-touch Update Software (Windows & Mac)

• Wireless Network Security: WEP 64/128 bit, 802.1x, LEAP (CKIP), EAP-FAST (TKIP/AES), PEAP, EAP-TLS, EAP-TTLS, WPA/PSK (TKIP/AES), WPA2-PSK (AES), EAP (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)

What's Included

• Carton Contents: Software, USB Cable, AC Adapter, Quick Setup Guide, Documentation, Starter rolls: DK-1201 Die-cut Standard Address Labels (100 labels), plus DK-2251 2.4" (62mm) Continuous Length Black/Red on White Paper Tape 16.4 ft. (5m)
