Features

• High-speed image processing technologies

• Full Color Dual CIS

• Capture and Record of OCR, MICR and Barcode / Deposit full color images

• Can be installed more than 40 currencies

• Mix & Multi currency mode (Count mixed currencies and automatic recognition)

• Advanced sensor technologies

• Equipped with range of counterfeit detection technologies

• Reliable fitness sorting

• Excellent tape detection performance

• Remote monitoring system by 'SIM'

• Connect with SIM link

• User-friendly system

• 2 Teller mode indicator and Multi user mode available

• 4.3” Full color touch screen

• Easily look up the all sensor data

• Simple and easy operation

• Easy maintanance

• iH-110 series is an ideal choice for:
  Bank branches, Casinos, Exchange offices, Public offices, Retailers, Cash centers

Specifications

• Currency: More than 40 currencies, up to 16 currencies (Mix & Multi)

• Operating Speed (can be installed more than 40 currencies):

  • Value Counting with counterfeit detection: Max 1300 NPM Note per minute
    Depends on currency

  • Fitness sorting with counterfeit detection: Max 1000 NPM Note per minute
    Depends on currency

• Capture and Record: OCR, MICR, Tickets, etc.

• Capture and Record: Full color image with OCR

• Pocket Capacity:

  • Hopper

    • iH-110/iH-110S/iH-110B: Max 500 Notes

    • iH-110F/iH-110FS: Max 1000 Notes

  • Reject Pocket: 60 notes (Max 100 notes)

  • Stacker: 200 notes (Max 300 notes)

• Display: 4.3” Full Color LCD Touch Screen

• Mode: Mix (Face, Orientation) / Different Denomination (Face, Orientation) / Count / Serial No. / Fitness / etc

• Dimensions (W/D/H):

  • iH-110/iH-110S/iH-110B: 300 x 320 x 315mm

  • iH-110F/iH-110FS: 300 x 320 x 345mm

• Weight:

  • iH-110/iH-110S/iH-110B: 13kg

  • iH-110F/iH-110FS: 14.5kg

• Interface: LAN (Giga), USB (H), USB (S), RS232C x 2

• Power Supply: 100 ~ 240V ±10%, 1.2A ~ 0.6A, 50/60Hz

• Sensor info.:

  • Full Color dual CIS: 8 Images

  • IR transmission, IR reflection, RGB

  • Full line magnetic sensor (16 Channel)

  • Thickness (Tape) / Double detection sensor (12 Channel / 2 Channel)

  • UV Reflection (4 Channel), Transmission (4 Channel), Fluorescence (4 Channel)

• Options:

  • External LCD display

  • OSD (On Screen Display: Video surveillance system)

  • Thermal printer
