Tiandy TC-R3110 IBP8V3.0 10-Channel PoE NVR (1 HDD Slot, 80W PoE Budget)

The Tiandy TC-R3110 IBP8V3.0 is a 10-channel Network Video Recorder with integrated PoE, designed for mid to large-scale surveillance systems. It supports high-resolution video input, efficient compression, and reliable storage with flexible I/O. Key specifications include:

• Channels: 10

• Bandwidth: 80 Mbps incoming, 80 Mbps outgoing

• Supported Resolutions: up to 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF

• Preview Decoding Capability: 6MP×1, 5MP×1, 4MP×2, 3MP×2, 1080p×4, 720p×8, 4CIF×10

• Playback Decoding Capability: 6MP×1, 5MP×1, 4MP×1, 3MP×2, 1080p×3

• Video Output Interfaces: HDMI and VGA, supports up to 4K on HDMI output

• Compression Formats: S+265, H.265, S+264, H.264

• Audio: G.711A, G.711U, ADPCM_DIV4

• Network Protocols: ARP, DDNS, DHCP, DNS, HTTP, ICMP, IGMP, IPv4/IPv6, NTP, RTCP, RTP, RTSP, SSH, TCP, UDP, Unicast, UPnP

• USB Ports: 2 × USB 2.0

• Storage Interface: 1 × SATA (supports up to 10 TB)

• PoE Ports: 8 × RJ45, 10/100 Mbps, supports IEEE 802.3af/at

• PoE Budget: 80 W total; power per port up to 30 W (max current ~600 mA)

• Power Supply: DC 48 V, 2 A

• Power Consumption:

• Net Weight: 0.45 kg

• Gross Weight: 0.85 kg

• Boundary (Body) Dimensions: 252 × 252 × 43 mm

• Package Dimensions: 315 × 70 × 235 mm

• Operating Temperature: –10 °C ~ +55 °C

• Operating Humidity: 10% ~ 90% RH

• Storage Temperature: –10 °C ~ +55 °C

• Storage Humidity: 10% ~ 90% RH

• Alarm & Smart Features: Motion detection, mask alarm, video loss, PoE overload, disk errors, IPC voltage abnormal, IP/MAC conflict, RTC failure, etc.

• Third-Party Camera Support: ONVIF Profile S/T, RTSP, CGI, SDK

• UI / Languages / Compatibility: Multiple languages, web browser compatibility, P2P, etc.
