Ubiquiti POE-54V-80W Gigabit PoE Injector for EdgePoint Devices, 54V DC 80W

Specifications

• Model: POE-54V-80W

• Product Type: Power over Ethernet (PoE) Injector

• Compatibility: Designed for Ubiquiti EdgePoint devices, including EP-R8 and EP-S16

• Output Voltage: 54V DC

• Output Current: 1.5A

• Output Power: 80W

• Input Voltage: 100–240V AC, 50/60Hz

• Input Current: 0.8A @ 120V AC, 0.4A @ 240V AC

• Inrush Current: <80A Peak @ 120V AC, <120A Peak @ 230V AC

• Efficiency: 87%+

• Output Ripple: 1% Max.

• Switching Frequency: 100 kHz Max.

• Line Regulation: ≤ 3%

• Load Regulation: ≤ 5%

• Ethernet Port: Gigabit LAN port

• Powering Method: 4-Pair Powering (Pins 1, 2, 4, 5 (+) and Pins 3, 6, 7, 8 (-))

• Surge Protection: Yes

• Clamping Protection: Yes

• Maximum Surge Discharge: Yes

• Peak Pulse Current: Yes

• Earth Grounding: Yes

• Dimensions: 123 x 65 x 34 mm (4.8 x 2.6 x 1.3”)

• Weight: 299 g (10.6 oz)

• Operating Temperature: 0°C to 40°C (32°F to 104°F)

• Operating Humidity: 10% to 90% non-condensing
