UNV MW3586-U-X 86Inch 4K Smart Interactive Display, 8GB RAM, 128GB Storage, 350 nits Brightness, 8GB RAM + 128GB Storage, 350 nits Brightness, 32-point touch, inbuilt Wi-Fi,  15W x 2 speaker, Android 13, Google Playstore supported

Specifications

Panel

• Panel Size: 86"

• Resolution: 3840 x 2160

• Brightness (cd/m²): 350

• Contrast Ratio: 1200:1

• Response Time (ms): 8

• Color Support: 1.07B

• Viewing Angle (H/V): 178°/178°

• Refresh rate (Hz): 60

• Color gamut: 72%

• Lifespan: 50000H

• Surface Hardness: 9H (7 on the Mohs scale)

• Haze Value: 25%

• Display Size (mm): 1895.04 x 1065.96

• Pixel Pitch (H x V) (mm): 0.49 x 0.49

System

• RAM: DDR4, 4GB

• ROM: eMMC, 32GB

• CPU: Amlogic T982 quad‑core A55

• CPU Frequency: 1.9GHz

• Operation System: Android 13.0

Touch

• Touch Control: Supports 32‑point touch, 20‑point write

• Recognizable Object: 5 points, 3mm

• Touch Precision (mm): 1

• Glass: 4mm tempered glass, 7H (Mohs), anti‑glare

• Touch Response Time (ms): ≤5

• Touch Technology: Infrared touch

Interface

• Video Input: 2 x HDMI IN (4K@60), 2 x AV analog video input

• Video Output: 1 x AV analog video output

• Audio Output: 1 x earphone, 3.5mm interface

• Other Interfaces: 1 x SPDIF, 1 x RS232, 1 x USB 3.0, 4 x USB 2.0, 1 x USB Type‑C, 2 x TOUCH OUT

• Network: 1 x RJ45, supports 10M/100M Base‑T self‑adaptive

General

• Operating Voltage: AC 100V to 240 V, 50/60 Hz

• Overall Power Consumption (W): 236

• Product Dimensions (W x H x D) (mm): 1969.8 x 1151 x 115.9 (Without camera)

• Package Dimensions (W x H x D) (mm): 2085 x 1276 x 220

• Weights: Net Weight: approximately 58 kg (without camera) Gross Weight: approximately 79 kg (without camera)

• Operating Temperature: 0°C to 50°C

• Operating Humidity: 10% to 90% RH (noncondensing)

• Accessories Included: 1 x power cable, 2 x touch pen, 1 x quick guide, 1 x wall mount bracket, 1 x infrared remote control, 3 x rod antenna

Audio

• Speaker: 2.0 sound channel

  • Left channel: 1 x 15W, 8Ω

  • Right channel: 1 x 15W, 8Ω

Wi‑Fi

• Wi‑Fi Configuration: Built‑in dual‑frequency Wi‑Fi 5 module

• Supports AP and station modes

• Wi‑Fi Performance: Up to 20m transmission distance in open space

Bluetooth

• Bluetooth Version: 5.0

OSD

• Multi-Language: 23 (Simplified Chinese, Traditional Chinese, Japanese, German, English, Spanish, French, Italian, Portuguese, Russian, Korean, Vietnamese, Ukrainian, Hungarian, Polish, Thai, Arabic, Kazakh, Bulgarian, Galician, Catalan, Uzbek, Indonesian)
