Tiandy TC-C34XN 4MP Fixed IR Turret Camera – SuperLite 2.8mm Lens, Built-in Mic, PoE, IP67
Estimated delivery within UAE 1–2 working days
Delivery to other countries 3–5 working days
-
Resolution: 4MP (2688×1520) @ 25 fps
-
Lens: 2.8mm fixed, F1.6, 92.8° FOV
-
Illumination: 0.02 Lux (color), 0 Lux (B/W with IR)
-
IR Range: Up to 30m with Smart IR
-
Audio: Built-in microphone
-
Compression: S+265, H.265, H.264
The Tiandy TC-C34XN 4MP Fixed IR Turret Camera (Spec: I3/E/Y/2.8mm/V4.2) is engineered for high-resolution surveillance with advanced features:
-
Image Sensor: 1/2.9" CMOS
-
Resolution: Up to 2688×1520 pixels
-
Frame Rate: 25 fps
-
Lens: 2.8mm fixed focal length, F1.6 aperture
-
Field of View: 92.8° (horizontal), 52.2° (vertical), 106.5° (diagonal)
-
Minimum Illumination:
-
Color: 0.02 Lux @ F1.6 (AGC ON)
-
B/W: 0 Lux (with IR)
-
-
IR Illumination:
-
Smart IR: Yes
-
IR Range: Up to 30 meters
-
Warm Lights: 2 LEDs, 15 meters
-
-
Audio: Built-in microphone
-
Video Compression: S+265, H.265, H.264
-
Wide Dynamic Range (WDR): Digital WDR
-
Signal-to-Noise Ratio (S/N): >40 dB
-
Power Supply:
-
DC12V ±25%: Max 6.5W
-
PoE (IEEE 802.3af): Max 7W
-
-
Operating Conditions:
-
Temperature: –30°C to 60°C
-
Humidity: 0% to 95% RH (non-condensing)
-
-
Ingress Protection: IP67
-
Housing: Metal + Plastic
-
Mounting: Wall or ceiling mountable
-
Dimensions: 80mm (diameter) × 220mm (length)
-
Weight: Approx. 500g
