Ubiquiti U7 Outdoor

Ubiquiti UniFi U7 Outdoor – High-Performance WiFi 7 Outdoor Access Point

The UniFi U7 Outdoor is a powerful, weather-resistant access point designed to deliver next-generation WiFi 7 (802.11be) performance in outdoor environments. Featuring cutting-edge wireless technology and enterprise-grade reliability, the U7 Outdoor is optimized for high-density deployments in parks, campuses, stadiums, and large public spaces.

Built with dual-band support across 2.4 GHz and 5 GHz, the U7 Outdoor achieves blazing-fast wireless speeds of up to 4.3 Gbps on 5 GHz (using 240 MHz channel bandwidth) and 688 Mbps on 2.4 GHz, leveraging 2x2 MU-MIMO technology on both bands for efficient client distribution and higher throughput. With support for WiFi 7, WiFi 6, and WiFi 5, it ensures compatibility across a wide range of modern and legacy devices.

Its antenna system combines a high-gain directional internal antenna with two external omni antennas, delivering flexible beam coverage (45° at 5 GHz, 90° at 2.4 GHz), and it supports external antennas via RP-SMA connectors. This enables customized signal coverage based on the deployment scenario, whether targeting specific areas or achieving broad 360° reach.

The U7 Outdoor is packed with enterprise features, including:

• Wireless meshing for cable-free expansion
• Band steering and client isolation
• 802.11r/k/v for fast and seamless roaming
• Advanced guest network options with custom captive portals, voucher/password/payment authentication
• Private Pre-Shared Keys (PPSK) for secure multi-user access
• WiFi speed limits, scheduling, and dynamic VLAN assignment via RADIUS

Physically robust, the U7 Outdoor is built with a UV-stabilized polycarbonate and aluminum alloy enclosure, capable of withstanding extreme temperatures from -30°C to 60°C and operating in humid environments (up to 95% non-condensing). It's wind-resistant up to 200 km/h, making it ideal for long-term outdoor installations.

The unit mounts easily to poles (1–2.36 inches in diameter) and includes a 1/2.5 GbE Ethernet port for uplink, supporting PoE input (42.5–57V DC) and consuming a maximum of 19W. Integrated status LEDs provide instant visual feedback on system and mesh performance.

Managed via the UniFi Network platform (version 8.2.93 or later), administrators can easily configure, monitor, and scale deployments using the UniFi Controller’s intuitive interface. With full NDAA compliance and certifications including CE, FCC, and IC, the UniFi U7 Outdoor is a reliable, secure, and future-ready solution for demanding wireless environments.
